The WLL Turbine Digital Flowmeter are used with ammonium, plating solutions, caustic and acidic cleaning agents, fuel products and chemicals. The lithium battery powered Digital LCD display, this flowmeter are calibrated to read in gallons and liters , and flowmeter come in BSPT3/4",BSPT 1",BSPT1-1/2" models.
Main Feature:
1.Model: WLL Turbine Digital Flowmete
2.Display: Digital LCD
3.Structure: Inline turbine flowmeter
4.Material :Aluminum
5.Size: BSPT 3/4",BSPT1",BSPT1-1/2"
6.Flow Rate: BSPT 3/4" 2-20gpm , BSPT1" 5-50gpm , BSPT1-1/2" 10-100gpm
7.Accuracy: BSPT 3/4" ±1% , BSPT1" ±1% , BSPT1-1/2" ±0.5%
8.Repeatability:0.1%
9.Temperature:-40°c-120 °c
10.Max pressure: 300PSI
11.Battery:Lithium batteries
Technical Specification:
| Fitting Type: | NPT or BSP (Female) | |
| Housing Material: | Aluminum | |
| Meter Sizes Available: | 3/4” 1” 1-1/2” | |
| Flow Range: | 3/4” | 2 - 20 GPM (7.6 - 75.7 LPM) |
| 1” | 5 - 50 GPM (18.9 - 190 LPM) | |
| 1-1/2” | 10 - 100 GPM (38.0 - 380 LPM) | |
| Accuracy (% of Reading): | 3/4” | ±1% |
| 1” | ±1% | |
| 1-1/2” | ±0.5% | |
| Repeatability: | ± 0.1% | |
| Pressure Rating: | 300 PSI / 21 BAR | |
| Operating TemperatureRange: | -40°F to +250°F (-40°C to +121°C) | |
